INA2143U Texas Instruments INA2143U Real Image
Same model may have multiple batches, images only for reference.
INA2143U Texas Instruments INA2143U Real Image
INA2143U Texas Instruments INA2143U Real Image
Same model may have multiple batches, images only for reference.

INA2143U

Part No INA2143U
Manufacturer Texas Instruments
Catalog Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description IC OPAMP DIFF 150KHZ 14SOIC
Datasheet
INA2143U Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Tube/Rail
Status Active
Amplifier Type Differential
Number of Circuits 2
Slew Rate 5 V/μs
-3db Bandwidth 150kHz
Voltage - Input Offset 100μV
Operating Supply Current 950μA
Channel Output Current 32mA
Supply Voltage - Operating 4.5 V to 36 V, ±2.25 V to 18 V
Temperature Range - Operating -40°C to 85°C
Mounting SMD (SMT)
Case / Package 14-SOIC
Win Source Part Number 082534-INA2143U
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian INA2143U CAD Model

Description

The INA2143U is a high-quality, superior performance instrument amplifier product manufactured by Texas Instruments, a globally renowned company specializing in semiconductor design and manufacturing.

  • Input: Dual, differential
  • Feature: User can set the gain accurately with external resistors
  • Feature: Input range includes the negative rail
  • Supply Range: ±2.25V to ±18V
  • Slew Rate: 20V/μs
  • Quiescent Current: 3.5mA per amplifier
  • Offset Voltage: 250μV
  • Offset Drift: 2μV/°C
  • Common-Mode Rejection Ratio (CMRR): 110dB
  • Package: 16-pin SOIC
  • Compliance: RoHS
