DRV8801EVM: Motor Driver Evaluation Module from Texas Instruments

The DRV8801EVM from Texas Instruments is an exemplary evaluation module that provides designers with a robust platform for testing and developing applications using the DRV8801 Single Brushed DC Motor Driver IC. This compact, high-performance module is specifically designed to drive a single brushed DC motor, making it an ideal tool for a wide range of projects in robotics, industrial control, and automation.

Key Features

• Integrated DRV8801 motor driver capable of delivering up to 2.8A of output current.
• Operates from a 8V to 36V supply voltage range, catering to various power requirements.
• Features a PH/EN (Phase/Enable) control interface for straightforward and efficient motor direction and speed regulation.
• Incorporates built-in protection features such as overcurrent, thermal shutdown, and under-voltage lockout, ensuring safe operation under diverse conditions.
• Comes with jumpers and connectors that provide flexible options for quick setup and interfacing with external control hardware.
• Includes a power-good LED indicator, which provides visual feedback on the operational status of the module.

Applications

The versatility of the DRV8801EVM makes it suitable for a broad spectrum of applications. It is particularly effective for driving small to medium-sized brushed DC motors commonly found in:

• Automated robotic systems
• Consumer electronics
• Office automation machines
• Power tools and appliances

Design Support

Texas Instruments provides extensive design support for the DRV8801EVM, including detailed documentation, reference designs, and the TI E2E™ support community forums. Engineers and developers can access a wealth of resources to accelerate the design process and bring their products to market faster.

Whether you're prototyping a new idea or refining an existing design, the DRV8801EVM offers a convenient and reliable solution for your motor driving needs.
