DAC121S101CIMKX/NOPB

Part No DAC121S101CIMKX/NOPB
Manufacturer Texas Instruments
Catalog Data Acquisition - Digital to Analog Converters (DAC)
Description 12-Bit Micro Power, RRO Digital-to-Analog Converter
Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits (ICs)
Manufacturer Texas Instruments
Packaging Reel - TR
Resolution 12
Number of D/A Converters 1
Settling Time 10μs
Output Type Voltage - Buffered
Data Interface SPI, DSP
Reference Type Supply
Operating Supply Voltage 2.7 V ~ 5.5 V
Voltage - Supply, Digital 2.7 V ~ 5.5 V
INL/DNL (LSB) ±8 (Maximum), ±0.5/+1 (Maximum)
Architecture String DAC
Operating Temperature Range -40°C ~ 105°C
Package SOT-23-6 Thin, TSOT-23-6
Manufacturer Package TSOT-23-6
Win Source Part Number 1166406-DAC121S101CIMKX/NOPB
Manufacturer Homepage www.ti.com
Popularity Medium
Supply and Demand Status Balance
Family Name DAC121S101
Introduction Date June 17, 2005
ECCN 3A991.c.2
Country of Origin Malaysia
Halogen Free Compliant
Estimated EOL Date 2028
Ultra Librarian 3D Model Ultra Librarian DAC121S101CIMKX/NOPB CAD Model

Description

Product Overview: DAC121S101CIMKX/NOPB

The DAC121S101CIMKX/NOPB is a high-performance, 12-bit, single-channel Digital-to-Analog Converter (DAC) from Texas Instruments, designed to deliver precision and reliability for a wide array of applications. This component is part of Texas Instruments' extensive line of data converters that combine innovative design and advanced process technology to meet the demands of modern electronic systems.

Key Features

  • Resolution: The DAC121S101CIMKX/NOPB offers a 12-bit resolution, providing fine-grain output voltage control for precise analog signal generation.
  • Update Rate: It features a fast settling time and is capable of a 1 MSPS update rate, making it suitable for high-speed applications where quick response times are critical.
  • Supply Voltage: Operating from a single 2.7V to 5.5V supply, this DAC is versatile and can fit into a variety of low-voltage or battery-powered systems.
  • Low Power Consumption: Its low power consumption is ideal for portable and battery-operated equipment, as it helps to extend the operational life of the product.
  • Packaging: The device comes in a compact, 6-pin SOT-23 package, which saves valuable board space and is suitable for space-constrained applications.
  • Interface: It features a simple, SPI-compatible serial interface that operates with a clock rate up to 30 MHz, enabling easy integration with most microcontrollers and digital systems.

Applications

The DAC121S101CIMKX/NOPB is used in a wide range of applications, including:

  • Portable Instruments
  • Data Acquisition Systems
  • Industrial Process Control
  • Digital Gain and Offset Adjustment
  • Programmable Voltage and Current Sources
  • Medical Instruments

Quality and Reliability

With the NOPB (No Lead (Pb)) designation, this device is RoHS compliant, making it suitable for use in environmentally sensitive applications. Texas Instruments is known for rigorous testing and quality control, ensuring that the DAC121S101CIMKX/NOPB meets the highest industry standards for performance and reliability.

Whether you are designing a sophisticated industrial system or a simple analog interface, the DAC121S101CIMKX/NOPB from Texas Instruments offers a blend of performance, power efficiency, and space-saving design that can help you achieve your design goals.
