Product Overview: CDCLVC1108PW from Texas Instruments

The CDCLVC1108PW is a high-performance, low-voltage clock buffer from Texas Instruments designed to distribute a single input clock to multiple outputs with minimal skew and jitter. This device is a part of TI's clock distribution portfolio, tailored for applications that require reliable and precise clock distribution networks.

Key Features

• Low-Voltage Operation: The CDCLVC1108PW operates at a supply voltage range of 1.6V to 3.6V, making it suitable for low-power applications.
• Multiple Outputs: It features eight low-skew, low-jitter buffered outputs that maintain signal integrity across the distribution network.
• High-Speed: The device supports clock frequencies up to 200MHz, providing the speed necessary for high-performance systems.
• Low Skew: Output-to-output skew is minimized, which is critical for maintaining synchronous operations in digital systems.
• Output Enable (OE) Function: The inclusion of an OE pin allows for the outputs to be enabled or disabled, offering flexibility in power management and signal routing.
• Industrial Temperature Range: It is designed to operate over an industrial temperature range of -40°C to 85°C, ensuring reliability in harsh environments.

Applications

The CDCLVC1108PW is versatile and can be used in various applications, including:

• Networking equipment such as routers, switches, and base stations
• Telecommunications infrastructure
• Data acquisition systems
• Test and measurement equipment
• High-speed digital systems that require precise clock distribution

Package and Quality

Enclosed in a 14-pin TSSOP (Thin Shrink Small Outline Package), the CDCLVC1108PW is designed for space-saving on PCBs without compromising performance. Texas Instruments is committed to high-quality standards and the CDCLVC1108PW is no exception, meeting stringent requirements to ensure reliability and functionality across its lifespan.

For engineers and designers looking for a robust clock distribution solution, the CDCLVC1108PW from Texas Instruments provides a high-performance, reliable option that can be integrated into a wide range of electronic systems.
