The CC2592RGVR from Texas Instruments is a high-performance, low-power RF front end designed for use with TI's CC25XX and CC85XX series of wireless microcontrollers. As a range extender, the CC2592 significantly increases the link budget and range for wireless applications operating in the sub-1 GHz and 2.4 GHz bands.

Key Features

• Frequency Range: The device supports a wide frequency range, making it suitable for a variety of wireless communication standards, including Zigbee, Bluetooth Low Energy (BLE), and proprietary protocols.
• Integrated Power Amplifier (PA): The CC2592 comes with an integrated class-leading PA that delivers high output power to extend the range of wireless communications.
• Low-Noise Amplifier (LNA): It also includes an LNA for improved receiver sensitivity, which is crucial for low-power and long-range applications.
• Switch: The integrated T/R switch allows for single-antenna operation, simplifying the RF design and reducing external component count.
• Power Management: The device includes power-saving features that make it ideal for battery-operated devices where power efficiency is key.

Applications

The CC2592RGVR is designed for wireless applications requiring extended range and robust link performance. It is suitable for:

• Home automation
• Smart grid and meter reading
• Wireless sensor networks
• Industrial control and monitoring
• Consumer electronics

Technical Specifications

The device is housed in a compact QFN package and is characterized for operation from -40°C to 85°C. It requires minimal external components, which reduces the overall solution size and bill of materials cost.

Design Support

Texas Instruments provides comprehensive design support for the CC2592, including evaluation modules, reference designs, technical documentation, and software tools to facilitate rapid development and time-to-market for designers working with this RF front end.
