The Texas Instruments BQ24305DSGR is a highly integrated circuit designed for the protection of Li-ion and Li-polymer batteries. It is a perfect solution for portable devices that require both efficient power management and robust protection for their power source. This advanced chip comes in a compact 8-pin WSON package, making it suitable for space-constrained applications.
Key Features
- Voltage Protection: The BQ24305DSGR offers overvoltage protection that guards the battery from inputs exceeding the overvoltage threshold, ensuring the longevity and reliability of the battery.
- Current Management: It features an integrated charge pump with dual N-channel MOSFET power switches for charging current management, which helps in maintaining optimal charging conditions.
- Thermal Protection: With a built-in thermal shutdown feature, the device ensures that both the battery and the circuit remain within safe operating temperatures.
- Status Indicators: The IC includes status flag outputs that indicate fault conditions, charge status, and power good, which simplifies the monitoring of battery health and charging progress.
Applications
The BQ24305DSGR is suited for a variety of applications where battery protection and management are critical. These include:
- Smartphones and Tablets
- Portable Media Players
- Handheld GPS Units
- Digital Cameras
- Other Portable Devices
Technical Specifications
| Parameter |
Value |
| Package Type |
8-pin WSON |
| Overvoltage Threshold |
Programmable |
| Operating Temperature Range |
-40°C to 85°C |
| Charge Pump |
Dual N-channel MOSFET |
For designers and engineers looking for a reliable battery protection solution, the Texas Instruments BQ24305DSGR offers a blend of performance, integration, and safety features that make it an excellent choice for next-generation portable electronics.
