The Texas Instruments ADS7835EVM is a comprehensive evaluation module designed for the ADS7835, a high-performance, single-channel, 12-bit analog-to-digital converter (ADC). This evaluation module (EVM) serves as a robust platform for engineers and designers to explore the capabilities, features, and performance of the ADS7835 ADC in various applications.

Key Features of the ADS7835EVM

• Direct Connectivity: The ADS7835EVM is equipped with connectors that allow for easy interfacing with test equipment and signal sources, facilitating quick setup and testing.
• Onboard Reference: A precision voltage reference is included on the EVM to ensure accurate ADC performance and to simplify the evaluation process.
• Flexible Power Options: The module supports various power configurations, enabling users to power the EVM through external power supplies or test equipment.
• User-Friendly Interface: The layout of the EVM is designed for accessibility, with clearly labeled test points and jumpers for easy configuration and signal routing.

Applications

The ADS7835EVM is ideal for evaluating the ADS7835 ADC in a wide range of applications, including:

• Data acquisition systems
• Industrial process control
• Medical instrumentation
• Battery-powered devices
• Portable instrumentation

Technical Specifications

The ADS7835EVM boasts a set of technical specifications that highlight the ADC's performance:

• 12-bit resolution with no missing codes
• Sample rate of up to 100 kSPS (kilo-samples per second)
• Single +5V power supply operation
• Serial interface with SPI™/QSPI™/MICROWIRE™ compatibility

Support and Resources

Texas Instruments provides extensive support and resources for the ADS7835EVM, including detailed documentation, reference designs, and technical support to ensure a successful evaluation and integration of the ADS7835 ADC into various applications.

With the ADS7835EVM, Texas Instruments continues its commitment to providing high-quality tools that enable innovation and streamline product development.
