T9AV2XD16-12 TE Connectivity – Price, Stock & Datasheet
Same model may have multiple batches, images only for reference.

T9AV2XD16-12

Part No T9AV2XD16-12
Manufacturer TE Connectivity
Catalog Power Relays, Over 2 Amps
Description RELAY GEN PURPOSE SPST 15A 12V
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Mounting Type Through Hole
Coil Voltage 12VDC
Contact Form SPST-NC (1 Form B)
Contact Rating (Current) 15 A
Switching Voltage 277VAC - Max
Load - Max Switching 4155VA
Coil Current 83.3 mA
Coil Type Non Latching
Termination Style PC Pin
Seal Rating Sealed - Flux Protection
Coil Insulation Class F
Must Operate Voltage 9 VDC
Must Release Voltage 1.2 VDC
Operate Time 15 ms
Release Time 15 ms
Temperature Range - Operating -55°C ~ 85°C
Approval Agency cURus
Relay Type General Purpose
Package Tray
Supply and Demand Status Shortage
Win Source Part Number 1549579-T9AV2XD16-12
Ultra Librarian 3D Model Ultra Librarian T9AV2XD16-12 CAD Model

Description

N
