Same model may have multiple batches, images only for reference.
HD16-6-96S Real Image
Same model may have multiple batches, images only for reference.

HD16-6-96S

Part No HD16-6-96S
Manufacturer TE Connectivity
Catalog Circular Connectors - Housings
Description CONN PLUG HSG FMALE 6POS INLINE / HD Circular Connectors
Datasheet
HD16-6-96S Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Connectors, Interconnects
Manufacturer TE Connectivity Deutsch Connectors
Series HD10
Packaging Bulk
Connector Type Plug Housing
Type For Female Sockets
Number of Positions 6
Shell Size - Insert 6-96
Contact Type Crimp
Contact Size 16
Mounting Free Hanging (In-Line)
Fastening Type Bayonet Lock
Orientation Keyed
Shell Material Polyamide (PA), Nylon, Glass Filled
Housing Color Gray
Ingress Protection IP68 - Dust Tight, Waterproof
Material Flammability Rating UL94 V-1
Features Coupling Nut
Shielding Unshielded
Note Contacts Not Included
Coupling Nut Diameter 1.452" (36.89mm)
Coupling Nut Material, Plating Polyamide (PA), Nylon, Glass Filled
Insert Material Polyamide (PA), Nylon, Glass Filled
Contact Shape Circular
Operating Temperature Range -40°C ~ 125°C
Win Source Part Number 772262-HD16-6-96S
Popularity Medium
Supply and Demand Status Limited
Family Name HD16
Introduction Date January 01, 2000
ECCN EAR99
Country of Origin Germany, Mexico, United Kingdom, United States of America
Halogen Free Not Compliant
Estimated EOL Date 2027
Ultra Librarian 3D Model Ultra Librarian HD16-6-96S CAD Model

Description

The TE Connectivity Deutsch Connectors HD10 series plug housing is designed for female sockets and has 6 positions.

  • Fastening Type: Bayonet Lock, Coupling Nut
  • Housing Material: Polyamide (PA), Nylon, Glass Filled
  • Flammability Rating: UL94 V-1
  • Housing Color: Gray
  • Ingress Protection: IP68 (Dust Tight and Waterproof)
  • Connector Type: Circular
  • Contact Type: Crimp
  • Operating Temperature Range: -40°C to 125°C
  • Shell Size: 6-96
  • Coupling Nut Diameter: 1.452" (36.89mm)
  • Packaging: Bulk
  • Country of Origin: Germany, Mexico, United Kingdom, United States of America
