Product photo
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Connector Type Receptacle
Contact Type Male Pin
Number of Positions 18
Pitch 0.205" (5.20mm)
Number of Rows 3
Row Spacing 0.236" (6.00mm)
Mounting Type Free Hanging (In-Line)
Contact Termination Crimp
Fastening Type Latch Lock
Insulation Material Polyamide (PA66), Nylon 6/6
Temperature Range - Operating -55°C ~ 105°C
Package Bag
Supply and Demand Status Normal
Win Source Part Number 1633087-925450-1
Ultra Librarian 3D Model Ultra Librarian 925450-1 CAD Model
