188275-8 Real Image
Same model may have multiple batches, images only for reference.

188275-8

Part No 188275-8
Manufacturer TE Connectivity
Catalog Card Edge Connectors - Edgeboard Connectors
Description CONN RCPT 8POS 0.1 TIN SMD / 8 Position Receptacle Connector 0.100" (2.54mm) Surface Mount Tin
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Connectors, Interconnects>Rectangular Connectors - Headers, Receptacles, Female Sockets
Mfr TE Connectivity AMP Connectors
Series Micro-MaTch
Package Tape & Reel
Connector Type Receptacle
Contact Type Forked
Style Board to Board or Cable
Number of Positions 8
Number of Positions Loaded All
Pitch - Mating 0.100" (2.54mm)
Number of Rows 2
Row Spacing - Mating 0.100" (2.54mm)
Mounting SMD (SMT)
Termination Solder
Fastening Type Push-Pull
Contact Finish - Mating Tin
Insulation Color Red
Insulation Height 0.209" (5.30mm)
Temperature Range - Operating -40°C ~ 105°C
Material Flammability Rating UL94 V-0
Contact Finish - Post Tin
Voltage Rating 100VDC
Applications Automotive, General Purpose
Insulation Material Polyamide (PA46), Nylon 4/6, Glass Filled
Contact Material Phosphor Bronze
Base Product Number 188275
MSL Level 1 (Unlimited)
REACH Status Vendor Undefined
ECCN EAR99
HTSUS 8536.69.4040
Other Names A107024TR,2266-188275-8TR,-188275-8-SI,1882758,A107024CT,-CA8112-000-SI-ND,188275-8-ND,-CA8112-000-SI,-CA8112-000-LSI,A107024DKR
Standard Package 900
Win Source Part Number 1035103-188275-8
Ultra Librarian 3D Model Ultra Librarian 188275-8 CAD Model

Description

The 1035103-188275-8 is a rectangular connector that belongs to the category of electronic components. It is designed to provide reliable and efficient connectivity between various electronic devices.

  • Win Source Part Number: 1035103-188275-8
  • Series: Micro-MaTch
  • Positions: 8
  • Applications: Automotive and General Purpose
  • Materials: Polyamide and Phosphor Bronze
  • Voltage Rating: 100VDC
