1744428-2 Real Image
Same model may have multiple batches, images only for reference.

1744428-2

Part No 1744428-2
Manufacturer TE Connectivity
Catalog Barrel - Power Connectors
Description CONN HEADER R/A 2POS 3.96MM  /  Connector Header Through Hole, Right Angle 2 position 0.156" (3.96mm)
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Connectors, Interconnects>Rectangular Connectors - Headers, Male Pins
Mfr TE Connectivity AMP Connectors
Series Economy Power
Package Bulk
Connector Type Header
Contact Type Male Pin
Pitch - Mating 0.156" (3.96mm)
Number of Positions 2
Number of Rows 1
Number of Positions Loaded All
Style Board to Cable/Wire
Shrouding Shrouded - 1 Wall
Mounting Type Through Hole, Right Angle
Termination Solder
Fastening Type Friction Lock
Contact Length - Mating 0.338" (8.59mm)
Contact Length - Post 0.142" (3.60mm)
Insulation Height 0.339" (8.61mm)
Contact Shape Square
Contact Finish - Mating Tin
Contact Finish Thickness - Mating 80.0µin (2.03µm)
Contact Finish - Post Tin
Contact Material Brass
Insulation Material Polyamide (PA), Nylon
Features Glow Wire Compliant
Temperature Range - Operating -25°C ~ 105°C
Material Flammability Rating UL94 V-0
Current Rating (Amps) 7.5A
Voltage Rating 250VAC
Contact Finish Thickness - Post 80.0µin (2.03µm)
Applications General Purpose, Industrial, Lighting
Base Product Number 1744428
MSL Level 1 (Unlimited)
REACH Status Vendor Undefined
ECCN EAR99
HTSUS 8536.69.4040
Other Names -1744428-2-CSI,-1744428-2-SI,A116514
Standard Package 1,000
Win Source Part Number 1174397-1744428-2
Ultra Librarian 3D Model Ultra Librarian 1744428-2 CAD Model

Description

The TE Connectivity AMP Connectors Economy Power series is a shrouded header that is designed for various applications. The TE Connectivity AMP Connectors Economy Power series is a shrouded header.

  • Number of Positions: 2
  • Positions Loaded: All
  • Voltage Rating: 250VAC
  • Current Rating: 7.5A
  • Contact Material: Brass
  • Contact Finish: Tin
  • Insulation Material: Polyamide (PA), Nylon
  • Package: Bulk
  • Standard Package: 1,000
  • Operating Temperature: -25°C ~ 105°C
