PH75F28015 Real Image
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Case / Package Module
Current - Output 1 5 A
Features OCP, OVP
Height 12.7 mm
Isolation Voltage 3 kV
Length 86.106 mm
Max Input Voltage 400 V
Max Operating Temperature 85 °C
Max Output Current 5 A
Max Power Dissipation 75 W
Min Input Voltage 200 V
Min Operating Temperature -20 °C
Mount Through Hole
Number of Outputs 1
Number of Pins 12
Output Current 5 A
Output Power 75 W
Output Voltage 15 V
Packaging Bulk
RoHS Compliant
Voltage - Output 1 15 V
Width 61.976 mm
Win Source Part Number 1221922-PH75F28015
Categories Board Mount Modules
Manufacturer TDK-Lambda Americas Inc.
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian PH75F28015 CAD Model

Description

The TDK-Lambda Americas Inc. PH75F28015 is a board mount module that features OCP and OVP from TDK-Lambda Americas Inc.

  • Features: OCP, OVP
  • Length: 86.106mm
  • Width: 61.976mm
  • Height: 12.7mm
  • Pins: 12
  • Isolation Voltage: 3 kV
  • Output Channels: 1
  • Output Current: 5A
  • Output Voltage: 15V
  • Input Voltage (Max): 400V
  • Input Voltage (Min): 200V
  • Operating Temperature: -20°C to 85°C
  • Power Dissipation (Max): 75W
  • RoHS: Compliant
  • Supply: Limited
