AA.170.301111

Part No AA.170.301111
Manufacturer Taoglas Limited
Catalog RF Antennas
Description RF ANT 1.561/1.575GHZ CER PATCH
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

RF Family/Standard Navigation
Frequency Group UHF (1GHz ~ 2GHz)
Frequency (Center/Band) 1.561GHz, 1.575GHz, 1.602GHz
Frequency Range 1.559GHz ~ 1.61GHz
Antenna Type Ceramic Patch
Number of Bands 3
VSWR 2
Gain 5.76dBi, 4.46dBi, 5.98dBi
Features Cable - 3m, LNA, Filter
Termination SMA Male
Ingress Protection IP65
Mounting Type Magnetic
Height (Max) 0.673" (17.10mm)
Applications Beidou, GLONASS, GPS
Package Bag
Supply and Demand Status Shortage
Win Source Part Number 1510796-AA.170.301111
Ultra Librarian 3D Model Ultra Librarian AA.170.301111 CAD Model
