SMAJ22

Name: SMAJ22
Brand: Taiwan Semiconductor
SKU: 668579
Availability: InStock
Rating: 4.85 (5 reviews)

Get a Quote

Part No	SMAJ22
Manufacturer	Taiwan Semiconductor
Catalog	TVS - Diodes
Description	400W, 27.1V, 10%, UNIDIRECTIONAL / 39.4V Clamp 10.2A Ipp Tvs Diode Surface Mount DO-214AC (SMA)
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Circuit Protection - Transient Voltage Suppressors (TVS) - TVS Diodes
Mfr	Taiwan Semiconductor
Series	SMAJ
Package	Tape & Reel
Product Status	Active
Type	Zener
Unidirectional Channels	1
Voltage - Reverse Standoff (Typ)	22V
Voltage - Breakdown (Min)	24.4V
Voltage - Clamping (Max) @ Ipp	39.4V
Current - Peak Pulse (10/1000µs)	10.2A
Power - Peak Pulse	400W
Power Line Protection	No
Applications	General Purpose
Temperature Range - Operating	-55°C ~ 150°C (TJ)
Mounting Type	Surface Mount
Package / Case	DO-214AC, SMA
Supplier Device Package	DO-214AC (SMA)
Base Product Number	SMAJ22
Standard Package	7,500 pcs
REACH Status	REACH Unaffected
ECCN	EAR99
HTSUS	8541.10.0080
Win Source Part Number	668579-SMAJ22
Ultra Librarian 3D Model	Ultra Librarian SMAJ22 CAD Model

Description

The SMAJ22 is a Zener type TVS diode designed to protect sensitive electronics from voltage transients induced by lightning and other transient voltage events.

Reverse Standoff Voltage: 22V
Breakdown Voltage: 24.4V
Clamping Voltage: 39.4V @ a peak pulse power of 400W
Channel: Unidirectional
Mounting Type: Surface mount
Package: DO-214AC (SMA)
Standard Package: 7,500 pieces
Operating Temperature: -55°C to 150°C
Status: Active
Manufacturer: Taiwan Semiconductor
Applications: Circuit protection
