The SG6901ARZ is a highly integrated Green-Mode PWM controller optimized for off-line flyback converter applications. It's designed to minimize standby power consumption and maximize efficiency, meeting the demands of modern energy-efficient power supplies.

Applications

• AC/DC adapters for portable devices (smartphones, tablets, etc.)
• Offline power supplies for home appliances
• Standby power supplies for consumer electronics (TVs, set-top boxes)
• LED lighting drivers

Features

• Green-mode operation for high efficiency at light loads
• Low startup current
• Low operating current
• Current-mode PWM control
• Built-in leading-edge blanking
• Programmable switching frequency
• Internal slope compensation
• Cycle-by-cycle current limiting
• Over-voltage protection (OVP)
• Overload protection (OLP)
• Short-circuit protection (SCP)
• Over-temperature protection (OTP)

Benefits

• Significantly reduced standby power consumption, compliant with energy efficiency standards.
• Improved overall system efficiency, especially at light loads.
• Enhanced system reliability through comprehensive protection features.
• Simplified design with fewer external components.
• Reduced system cost.

Additional Details

The SG6901ARZ uses a proprietary green-mode control scheme to minimize switching losses at light loads, improving overall efficiency. It incorporates a comprehensive set of protection features to safeguard the power supply from abnormal operating conditions. Detailed specifications regarding switching frequency range, voltage and current ratings, and protection thresholds are available in the product datasheet provided by System General.
