Products specifications Report Issue?

Category Discrete Semiconductor Products - Diodes - Rectifiers - Single Diodes
Mfr Surge Components
Package Bag
Product Status Active
Technology Schottky
Voltage - DC Reverse (Vr) (Max) 100 V
Current - Average Rectified (Io) 5A
Voltage - Forward (Vf) (Max) @ If 790 mV @ 5 A
Speed Fast Recovery =< 500ns, > 200mA (Io)
Current - Reverse Leakage @ Vr 30 µA @ 100 V
Capacitance @ Vr, F 96pF @ 4V, 1MHz
Mounting Type Surface Mount
Package / Case DO-214AB, SMC
Supplier Device Package DO-214AB (SMC)
Operating Temperature - Junction -55°C ~ 150°C
Standard Package 1 pcs
MSL Level 1 (Unlimited)
REACH Status Vendor Undefined
ECCN 3A001
HTSUS 8541.10.0080
Win Source Part Number 667588-SK5B
Ultra Librarian 3D Model Ultra Librarian SK5B CAD Model

Description

The 667588-SK5B is a fast recovery Schottky diode with a voltage rating of 100V and an average rectified current of 5A.

  • Forward Voltage @ 5A: 790mV
  • Reverse Leakage Current @ 100V: 30μA
  • Designed for: applications that require fast switching speeds and low forward voltage drop.
  • Package: surface mount DO-214AB (SMC)
  • Suitable for: automated assembly processes
  • Capacitance @ 4V and 1MHz: 96pF
  • Ideal for: high-frequency applications.
  • Operating Temperature Range: -55°C to 150°C
  • Suitable for: harsh environments.
  • Manufacturer: Surge Components
