XZVG56W SunLED XZVG56W label picture XZVG56W label picture 2 XZVG56W label picture 3 XZVG56W label picture 4 XZVG56W label picture 5 XZVG56W real image
Same model may have multiple batches, images only for reference.
XZVG56W SunLED XZVG56W label picture XZVG56W label picture 2 XZVG56W label picture 3 XZVG56W label picture 4 XZVG56W label picture 5 XZVG56W real image
XZVG56W SunLED XZVG56W label picture XZVG56W label picture 2 XZVG56W label picture 3 XZVG56W label picture 4 XZVG56W label picture 5 XZVG56W real image
Same model may have multiple batches, images only for reference.

XZVG56W

Part No XZVG56W
Manufacturer SunLED
Catalog LED Indication - Discrete
Description LED GREEN CLEAR 2SMD R/A
Datasheet
XZVG56W Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Optoelectronics - LED Indication - Discrete
Mfr SunLED
Package Tape & Reel
Product Status Active
Color Green
Configuration Standard
Lens Color Colorless
Lens Transparency Clear
Millicandela Rating 49mcd
Lens Style Rectangle with Domed Top
Lens Size 2.00mm x 1.00mm
Voltage - Forward (Vf) (Typ) 2.1V
Current - Test 20mA
Viewing Angle 120°
Mounting Type Surface Mount, Right Angle
Wavelength - Dominant 570nm
Wavelength - Peak 574nm
Package / Case 2-SMD, No Lead
Supplier Device Package 2-SMD
Size / Dimension 3.00mm L x 2.00mm W
Height (Max) 1.00mm
Base Product Number XZVG56
Standard Package 2,000 pcs
MSL Level 3 (168 Hours)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8541.41.0000
Win Source Part Number 743349-XZVG56W
Ultra Librarian 3D Model Ultra Librarian XZVG56W CAD Model

Description

The XZVG56W is a green LED indication component from SunLED.

  • Application: Surface Mount
  • Package: Tape & reel
  • Standard Package: 2,000 pcs
  • Viewing Angle: 120°
  • Millicandela Rating: 49mcd
  • Forward Voltage (Vf): 2.1V
  • Current Rating: 20mA
  • Peak Wavelength: 574nm
  • Height: 1.00mm
  • Mounting: Surface mount or right angle
  • Status: Active
