The VND5160J-E from STMicroelectronics is a sophisticated automotive-grade H-bridge driver, designed to deliver robust performance for driving inductive loads in automotive applications. This high-side driver is part of the VIPower M0-7 series and is tailored to meet the stringent requirements of the automotive industry, making it an ideal choice for driving DC motors, resistive, and inductive loads.

Key Features

• High Operating Voltage Range: The device operates over a broad voltage range, typically from 5.5V to 28V, providing versatility in various automotive voltage systems.
• High Current Capability: With a maximum continuous current rating of 20A, the VND5160J-E is capable of handling high current loads, making it suitable for demanding applications.
• Built-in Protection Features: The device includes a variety of protection mechanisms such as over-temperature shutdown, load current limitation, and overvoltage clamp, ensuring safe operation under adverse conditions.
• Diagnostic Functions: Integrated diagnostic features provide feedback on the status of the device and the system, such as open load detection and thermal shutdown status, which are crucial for system monitoring and troubleshooting.
• Low Standby Current: Energy efficiency is enhanced with a low standby current, reducing power consumption when the device is not actively driving a load.

Applications

The VND5160J-E is optimized for a variety of applications within the automotive sector. It is commonly used in:

• Automotive lighting systems, such as headlight and taillight controllers
• Motor control units for window lifters, seat adjustment, and HVAC blowers
• Solenoid and valve control in various systems

Quality and Reliability

STMicroelectronics is committed to delivering high-quality products. The VND5160J-E is manufactured to meet the rigorous ISO/TS16949 certification, which is specific to the automotive industry. This ensures that the device meets the highest quality and reliability standards required for automotive-grade components.
