Product Overview: VND5050AJTR-E

The VND5050AJTR-E is a robust automotive-grade double channel high-side driver manufactured by STMicroelectronics, a leader in the semiconductor industry. This product is part of the VIPower M0-5 family and is specially designed to drive automotive applications with outstanding efficiency and reliability.

Key Features

• Double Channel Output: The VND5050AJTR-E features two independent high-side drivers, allowing for the control of two separate loads with a wide range of current capabilities.
• High Voltage Capability: With an operating voltage range from 5.5V to 36V, this driver is suitable for handling the demanding electrical environments found in automotive applications.
• High Current Rating: Each channel can handle continuous current up to 12A, making it suitable for driving high-power loads such as motors, lamps, and solenoids.
• Thermal Shutdown: To protect the device and the load, the VND5050AJTR-E includes an overtemperature shutdown feature with auto-restart.
• Load Current Limitation: This safety feature prevents damage to the system by limiting the current in case of load surge or short-circuit conditions.
• Diagnostic Functions: Integrated diagnostic capabilities provide feedback on load status, open load detection in OFF-state, and overtemperature indication.
• Protection Features: The device includes an array of protection features like undervoltage shutdown, overload and short-circuit protection, and loss of ground and supply protections.

Applications

The VND5050AJTR-E is ideal for a variety of automotive applications, including but not limited to:

• Automotive interior or exterior lighting
• Control of motors for window lifters, wipers, or fans
• Automotive intelligent power distribution systems

Quality and Reliability

STMicroelectronics ensures that the VND5050AJTR-E meets the stringent requirements of the automotive industry. The device is qualified under AEC-Q100 standards, which guarantees high levels of quality and reliability for automotive electronics. Additionally, it is housed in a PowerSSO-12 package, which offers excellent thermal performance and is designed for compact PCB layouts.

With its robust design and comprehensive set of features, the VND5050AJTR-E from STMicroelectronics stands out as a high-performance solution for automotive high-side driving applications.
