Products specifications Report Issue?

Category Integrated Circuits (ICs) - Power Management (PMIC) - Full Half-Bridge Drivers
Mfr STMicroelectronics
Series STSPIN2
Package Tape & Reel
Product Status Active
Output Configuration Half Bridge (4)
Applications DC Motors, General Purpose
Interface PWM
Load Type Inductive
Technology Power MOSFET
Rds On (Typ) 400mOhm LS + HS
Current - Output / Channel 1.3A
Voltage - Supply 0V ~ 5V
Voltage - Load 1.8V ~ 10V
Temperature Range - Operating -40°C ~ 150°C (TJ)
Fault Protection Current Limiting, Over Temperature, Short Circuit
Mounting Type Surface Mount
Package / Case 16-VFQFN Exposed Pad
Supplier Device Package 16-VFQFPN (3x3)
Base Product Number STSPIN240
Standard Package 4,000 pcs
MSL Level 3 (168 Hours)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.39.0001
Win Source Part Number 742126-STSPIN240
Ultra Librarian 3D Model Ultra Librarian STSPIN240 CAD Model

Description

STSPIN240 Low-Voltage Dual Brush DC Motor Driver

The STSPIN240 from STMicroelectronics is a state-of-the-art dual brush DC motor driver designed for efficiency and flexibility. This integrated motor driver is part of ST's STSPIN family, known for its compact design and advanced features that cater to a wide range of low-voltage motor control applications.

The STSPIN240 is capable of operating at a voltage range from 1.8V to 10V, which makes it ideal for battery-powered applications such as portable devices, toys, and small appliances. Its low voltage capabilities also ensure reduced power consumption, contributing to the extended battery life of the devices it powers.

This motor driver integrates two independent bridge drivers, which can control two DC motors simultaneously. The full-bridge operation allows for easy direction and speed control, providing a versatile solution for complex movements and precision tasks. The motor driver also features a peak current of up to 1.3A, delivering sufficient power for a variety of small to medium-sized motors.

One of the key benefits of the STSPIN240 is its advanced protection features. It includes non-dissipative overcurrent protection, thermal shutdown, and under-voltage lockout, ensuring the safety and longevity of both the motor and the driver. This comprehensive protection scheme makes the STSPIN240 a reliable choice for critical applications where safety cannot be compromised.

For design flexibility, the STSPIN240 offers a standby mode that reduces power consumption when the motor is not in use. It also supports PWM, analog voltage, and advanced current control modes, providing designers with multiple control options to achieve the desired performance.

With its tiny QFN package, the STSPIN240 is not only powerful but also space-efficient, making it an excellent choice for compact PCB layouts. Whether you're developing a new portable gadget or upgrading an existing device, the STSPIN240 offers the perfect blend of power, precision, and size.

Overall, the STSPIN240 is a versatile and reliable solution for designers looking to drive low-voltage DC motors with ease and precision.
