The STM32F401CBU6TR is a high-performance microcontroller from the renowned semiconductor manufacturer STMicroelectronics. This device is part of the STM32F4 series, which is famous for its advanced ARM Cortex-M4 core with a floating-point unit (FPU). The STM32F401CBU6TR is designed to offer a balance between performance, power consumption, and cost, making it an ideal choice for a wide range of applications.
Key Features:
- Core: ARM Cortex-M4 with FPU, running at frequencies of up to 84 MHz.
- Memory: Equipped with 128 KB of Flash memory and 64 KB of SRAM, providing ample space for complex applications.
- Package: Available in a compact 48-pin UFQFPN package, which is suitable for space-constrained applications.
- Power Efficiency: Designed for energy-efficient operations, it includes multiple power-saving modes such as Sleep, Stop, and Standby.
- Peripherals: A rich set of peripherals including I2C, SPI, USART, and USB 2.0 OTG, enabling easy integration with other components and systems.
- ADCs: Features 12-bit analog-to-digital converters with up to 16 channels, providing precise sensing and measurement capabilities.
- Timers: Advanced-control timers, general-purpose timers, and basic timers to handle a wide range of timing and control tasks.
- Debugging: Integrated debugging and programming capabilities via SWD (Serial Wire Debug).
- Temperature Range: Operates within an industrial temperature range from -40°C to 85°C, ensuring reliability under various environmental conditions.
Applications:
The STM32F401CBU6TR microcontroller is versatile and can be used in numerous applications, including but not limited to:
- Industrial control systems
- Medical equipment
- Consumer electronics
- Home automation
- Internet of Things (IoT) devices
- Portable and wearable devices
With its robust architecture, comprehensive feature set, and STMicroelectronics' commitment to quality, the STM32F401CBU6TR is a reliable and cost-effective solution for your sophisticated design needs.
