Products specifications

Categories Circuit Protection
Manufacturer STMicroelectronics
Packaging Reel - TR
Status Active
Type Zener
Bidirectional Channels 4
STAND-OFF Voltage (Vwm) 2.8V
Max Clamping Voltage 15V
Peak Pulse Current(Ippm) 24A (8/20μs)
Power Dissipation - Pd 600W
Applications Ethernet
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package 8-SOIC
Win Source Part Number 1096879-SLVU2.8-4A1
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian SLVU2.8-4A1 CAD Model

Description

Introducing the SLVU2.8-4A1 from STMicroelectronics

The SLVU2.8-4A1 is a robust transient voltage suppressor (TVS) designed by STMicroelectronics, a leader in semiconductor solutions. This device is specifically engineered to protect sensitive electronics from voltage transients induced by system inductance, lightning, and electrostatic discharge (ESD). It is an optimal solution for safeguarding high-speed data lines and other vulnerable circuits.

Key Features

  • Low Clamping Voltage: The SLVU2.8-4A1 offers a low clamping voltage, ensuring that sensitive components are shielded from transient events without significant impact on the system performance.
  • High Surge Capability: With its ability to handle high surge currents, this device is capable of withstanding severe transient conditions, making it highly reliable for critical applications.
  • Low Capacitance: The design of the SLVU2.8-4A1 features low line capacitance, making it suitable for high-speed data lines as it minimizes signal attenuation.
  • Unidirectional Protection: It provides unidirectional transient voltage suppression, which is ideal for protecting power lines and other uni-polar applications.
  • SO-8 Package: Encased in a small-outline package, the SLVU2.8-4A1 is not only space-efficient but also offers excellent power dissipation characteristics.

Applications

The SLVU2.8-4A1 is versatile and can be used in a wide range of applications. It is particularly well-suited for:

  • USB 1.1 and 2.0 Power and Data Line Protection
  • 10/100 Ethernet Line Protection
  • Video Line Protection
  • Microcontroller Input Protection
  • Portable Electronics
  • Other Sensitive Data Line Applications

Reliability and Compliance

STMicroelectronics is committed to delivering high-quality products. The SLVU2.8-4A1 is compliant with the IEC 61000-4-2 and IEC 61000-4-5 standards, ensuring its reliability in protecting against ESD and surge events. It is also RoHS compliant, reflecting STMicroelectronics' dedication to environmental sustainability.

In summary, the SLVU2.8-4A1 from STMicroelectronics is a powerful solution for protecting electronic systems from voltage transients. Its combination of low clamping voltage, high surge capability, and low capacitance, all in a compact package, make it an excellent choice for safeguarding your sensitive electronic applications.
