The M95080-WDW6TP is a high-performance 8-Kbit serial EEPROM from STMicroelectronics, designed to deliver a flexible and reliable data storage solution for a wide array of applications. This EEPROM device utilizes the industry-standard SPI (Serial Peripheral Interface) bus, ensuring compatibility with a vast range of microcontrollers and digital systems.
Key Features
- Memory Size: The device features an 8-Kbit memory capacity, organized as 1,024 x 8 bits, which is ideal for storing configuration settings, calibration data, and small application logs.
- Interface: It operates with a high-speed SPI bus interface, supporting clock frequencies up to 10 MHz, which allows for fast data transfer and swift write operations.
- Write Protection: Enhanced data protection is provided through hardware and software write protection features, including Write Protect (WP) pins and Status Register bits to prevent accidental data overwrites.
- Supply Voltage Range: The M95080-WDW6TP operates over a wide supply voltage range from 2.5 V to 5.5 V, making it suitable for various electronic environments and applications.
- Temperature Range: This EEPROM is designed to perform reliably in extreme conditions, with an operating temperature range from -40°C to +85°C.
- Packaging: The device comes in a TSSOP8 package, which is known for its compact footprint and suitability for space-constrained applications.
Applications
The M95080-WDW6TP EEPROM is versatile and can be used in a variety of sectors including:
- Consumer Electronics
- Industrial Control Systems
- Automotive Systems
- Medical Devices
- Telecommunication Infrastructure
In conclusion, the M95080-WDW6TP from STMicroelectronics is a robust and reliable EEPROM solution that offers a blend of performance, flexibility, and protection features. Its compatibility with the SPI bus, wide voltage range, and temperature resilience make it an excellent choice for designers looking to integrate non-volatile memory into their applications.
