Overview of STMicroelectronics M24C32-RDW6TP

The M24C32-RDW6TP by STMicroelectronics is a 32-Kbit serial I²C bus EEPROM (Electrically Erasable Programmable Read-Only Memory) that is designed to provide a robust and efficient data storage solution for a wide range of electronic applications. This EEPROM device is part of STMicroelectronics' M24C series, known for its high performance and reliability.

Key Features

• Memory Size: The device offers a substantial 32-Kbit (4096 x 8 bits) storage capacity, suitable for applications requiring moderate amounts of non-volatile memory.
• Serial I²C Interface: It utilizes a two-wire I²C serial interface for communication, supporting up to 400 kHz (Fast-mode) and 1 MHz (Fast-mode Plus) for rapid data transfer.
• Write Cycle Time: Fast write cycle times of 5 ms (typical) enable swift data storage and updates.
• Operating Voltage Range: The device operates over a wide voltage range from 1.8 V to 5.5 V, making it versatile for various circuit designs and power requirements.
• Temperature Range: It is designed to perform reliably across a broad industrial temperature range from -40°C to +85°C.
• Write Protect: A hardware write protect feature is included, allowing the user to prevent accidental overwrite of data by setting the write protect pin.
• Endurance: The M24C32-RDW6TP provides high write endurance, with up to 1 million write cycles per byte and a data retention period of 40 years, ensuring data integrity over an extended period.
• Packaging: The EEPROM is available in a TSSOP8 package, which is well-suited for space-constrained applications.

Applications

The M24C32-RDW6TP EEPROM is ideal for a wide array of applications, including:

• Personal electronics and portable devices
• Industrial and medical equipment
• Automotive systems
• Data storage modules
• Smart cards and identification systems

With its robust feature set, the M24C32-RDW6TP from STMicroelectronics provides a reliable and flexible non-volatile memory solution for designers seeking to incorporate a dependable storage component into their electronic systems.
