STMicroelectronics M24C16-WMN6TP EEPROM

The M24C16-WMN6TP is a high-performance 16-Kbit serial EEPROM (Electrically Erasable Programmable Read-Only Memory) from the reputable semiconductor manufacturer STMicroelectronics. This device is particularly designed for flexible, non-volatile data storage in a broad array of electronic applications, from industrial to consumer electronics.

Featuring a 16-Kbit (2 Kbyte) memory capacity, the M24C16-WMN6TP ensures ample space for critical data storage such as device configuration, calibration data, and user preferences. The EEPROM operates on the standard I²C-compatible (two-wire) serial interface protocol, which allows for easy integration into most microcontroller-based systems with minimal pin count and straightforward interfacing.

The memory is organized as 2,048 x 8 bits, which allows for efficient data management and access. It supports a supply voltage range of 2.5V to 5.5V, making it versatile for various operating environments and compatible with both 3.3V and 5V logic levels. This feature ensures that the M24C16-WMN6TP can be used in systems with different power requirements without the need for additional level shifting or power regulation components.

One of the noteworthy features of the M24C16-WMN6TP is its Write Control function, which provides additional data protection. The device also offers byte and page write (up to 16 bytes), which can be completed in 5 ms, facilitating efficient data management and reducing write cycle times. Moreover, it is capable of withstanding up to 1 million write cycles and has a data retention period of 40 years, ensuring the reliability and longevity of the stored information.

The M24C16-WMN6TP comes in a compact SO-8N package, making it suitable for space-constrained applications. Its operating temperature range of -40°C to +85°C guarantees stable performance under varying environmental conditions.

In summary, the M24C16-WMN6TP from STMicroelectronics is a robust and reliable EEPROM solution that offers a mix of capacity, speed, and durability for a wide range of data storage applications. Its compatibility with standard communication protocols and its operational resilience make it an excellent choice for designers looking to incorporate non-volatile memory into their systems.
