STMicroelectronics LSM303DLHTR 3D Magnetometer and Accelerometer

The LSM303DLHTR is a high-performance system-in-package featuring a 3D digital linear acceleration sensor and a 3D digital magnetic sensor. Manufactured by STMicroelectronics, a global semiconductor leader, this compact module provides precise data for both acceleration and magnetic heading, making it an ideal choice for advanced navigation and motion-sensing applications.

Key Features

• 3D Magnetometer: The device includes a 3-axis digital magnetic sensor that can detect magnetic fields, providing compass-like functionality for accurate heading information.
• 3D Accelerometer: Alongside the magnetometer, a 3-axis digital accelerometer measures acceleration due to motion or gravity, enabling tilt-compensated compass functions and motion detection features.
• High Resolution: Both sensors offer high-resolution output, with the magnetometer having a range of ±1.3 to ±8.1 gauss and the accelerometer supporting ±2g/±4g/±8g dynamically selectable full scales.
• I2C Interface: The LSM303DLHTR communicates with microcontrollers via an I2C serial bus interface, ensuring easy integration into a wide range of systems.
• Compact Design: Its small form factor (LGA package) is perfect for space-constrained applications, including mobile devices, gaming controllers, and personal navigation systems.

Applications

The versatility of the LSM303DLHTR makes it suitable for a broad spectrum of applications. It is extensively used in:

• Smartphones and Tablets
• Personal Navigation Devices (PNDs)
• Vehicle Navigation Systems
• Robotics
• Unmanned Aerial Vehicles (UAVs)
• Game Controllers
• Sports and Fitness Devices

Environmental and Quality Certifications

STMicroelectronics ensures that the LSM303DLHTR meets rigorous environmental and quality standards. It is compliant with RoHS and designed to satisfy the demanding requirements of the automotive industry, reflecting ST's commitment to reliability and excellence.
