The L6472H from STMicroelectronics is a state-of-the-art, fully integrated microstepping motor driver with a motion engine and SPI interface, designed to drive bipolar stepper motors with unparalleled precision and ease. As part of the dSPIN family, it stands out for its advanced features and performance, making it an ideal choice for a wide range of applications requiring precise motor control.

Key Features

• Operating Voltage Range: The device operates on a supply voltage ranging from 8 to 45 V, providing the flexibility to be used in various application scenarios.
• Output Current Capacity: It can deliver up to 3 A of output current, ensuring robust performance for a variety of stepper motors.
• Advanced Microstepping: With up to 1/16 microstepping resolution, the L6472H allows for smooth and precise motor movement, which is critical for applications that demand high position accuracy.
• Integrated Motion Engine: The device features a built-in motion engine that offloads the host controller, simplifying the implementation of complex motion profiles with minimal software overhead.
• SPI Interface: The Serial Peripheral Interface (SPI) enables easy configuration and control while allowing for daisy-chaining of multiple devices for multi-motor applications.
• Overcurrent, Overtemperature, and Undervoltage Protection: These built-in protection features ensure the reliability and longevity of both the motor driver and the motor itself.
• Non-Dissipative Overcurrent Detection: This feature provides an additional layer of protection that prevents damage from overcurrent conditions without the loss of power.

Applications

The L6472H is highly versatile and can be used in a multitude of applications, including but not limited to:

• Office Automation (Printers, Scanners)
• ATM and Cash Handling Machines
• Textile, Sewing Machines
• Robotics and Factory Automation
• Medical Equipment
• Vending and Slot Machines

In summary, the L6472H from STMicroelectronics represents a cutting-edge solution for precise and efficient stepper motor control, providing designers with a highly integrated, feature-rich driver that simplifies the development of sophisticated motor control systems.
