Products specifications

Manufacturer STMicroelectronics
Packaging Reel
Type Steering (Rail to Rail)
Unidirectional Channels 2
Voltage - Reverse Standoff (Typ) 3V
Voltage - Breakdown (Min) 6V
Power Line Protection Yes
Applications Ethernet, HDMI
Capacitance at Frequency 0.6pF at 200MHz ~ 3GHz
Temperature Range - Operating -40°C ~ 150°C
Mounting Style SMD
Manufacturer Package 6-UFDFN
Supplier Device Package 6-uQFN (1.45x1)
Part Number Series HSP061
Manufacturer Pack Quantity 3,000
MSL Level 1 (Unlimited)
Popularity Medium
Supply and Demand Status Balance
Win Source Part Number 805291-HSP061-2M6
Ultra Librarian 3D Model Ultra Librarian HSP061-2M6 CAD Model

Description

Product Overview: HSP061-2M6 - STMicroelectronics

The HSP061-2M6 is a highly integrated ESD protection device designed by STMicroelectronics, a global semiconductor leader. This device is specifically engineered to safeguard high-speed interfaces against Electrostatic Discharge (ESD) and other voltage-induced transient events. It is an ideal solution for protecting sensitive electronic components in a variety of applications, including mobile phones, digital cameras, and other portable devices.

Key Features

  • High ESD Protection: The HSP061-2M6 offers robust ESD protection up to 15 kV, ensuring the safety and longevity of electronic components against static electricity and surges.
  • Low Capacitance: With a very low line capacitance, this device is suitable for protecting high-speed data lines without compromising signal integrity.
  • Low Leakage Current: It features a low leakage current, minimizing power consumption and making it suitable for battery-powered applications.
  • Multi-Line Protection: The device is capable of protecting up to 6 data lines, making it a compact and efficient solution for multi-line interfaces.
  • Small Package Size: The HSP061-2M6 comes in a small µQFN-10L package, which is ideal for space-constrained applications.

Applications

The HSP061-2M6 is versatile and can be used in a variety of applications where high-speed data line protection is crucial. It is particularly well-suited for:

  • USB 2.0 and 3.0 interfaces
  • HDMI 1.3 and 1.4 ports
  • DisplayPort interfaces
  • External storage interfaces
  • Smartphone and tablet data ports

Why Choose the HSP061-2M6?

STMicroelectronics' HSP061-2M6 stands out for its combination of high performance, low power consumption, and compact design. Its ability to protect multiple lines while maintaining signal integrity makes it a top choice for designers looking to enhance the durability and reliability of their high-speed digital interfaces. With its easy integration into existing PCB layouts, the HSP061-2M6 is a practical addition to any sensitive electronic system requiring robust ESD protection.
