Products specifications

Categories Circuit Protection
Manufacturer Nexperia USA Inc.
Packaging Reel - TR
Status Active
Type Steering (Rail to Rail)
Unidirectional Channels 4
STAND-OFF Voltage (Vwm) 5.5V (Max)
Power Line Protection Yes
Applications General Purpose
Capacitance @ Frequency 1pF @ 1MHz
Temperature Range - Operating -40°C to 85°C (TA)
Mounting SMD (SMT)
Case / Package 6-TSOP
Win Source Part Number 094439-IP4220CZ6
Family Name IP4220CZ6
Introduction Date September 17, 2004
ECCN EAR99
Country of Origin Malaysia
Halogen Free Compliant
Estimated EOL Date 2023
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Application Field Used in Industrial, Medical, Communications & Networking
Ultra Librarian 3D Model Ultra Librarian IP4220CZ6 CAD Model

Description

The IP4220CZ6 is an advanced ESD protection device from NXP Semiconductors, designed to safeguard high-speed data lines and other sensitive circuits from electrostatic discharge (ESD) and other voltage-induced transients. This component is particularly well-suited for applications that require robust protection while maintaining signal integrity, making it an ideal choice for a wide range of consumer electronics, including smartphones, tablets, and laptops.

Key Features

  • ESD Protection: The IP4220CZ6 offers exceptional ESD protection that meets IEC 61000-4-2 (Level 4) standards, ensuring devices are safeguarded against ESD pulses up to ±8 kV (contact discharge) and ±15 kV (air discharge).
  • Low Capacitance: With its low line capacitance, typically around 0.7 pF, this device preserves signal integrity, making it suitable for protecting high-speed data lines without compromising performance.
  • Low Clamping Voltage: The low clamping voltage ensures that even under ESD stress, the protected ICs will not be exposed to damaging voltage levels, thereby extending the life of the end product.
  • Multiple Channel Protection: The IP4220CZ6 integrates six protection channels in a single package, offering a compact solution for protecting multiple data lines while saving board space.
  • High Surge Current Capability: It can withstand high surge currents, ensuring reliable protection against transient voltage spikes that can occur in harsh electrical environments.

Applications

The versatile nature of the IP4220CZ6 makes it suitable for a variety of applications, including:

  • USB 2.0 power and data line protection
  • Mobile and portable devices
  • High-speed data line protection for consumer electronics
  • Peripheral ports protection

Package and Quality

The IP4220CZ6 is housed in a leadless, ultra-small DFN2020-6 (SOT1118) surface-mount package, which is RoHS compliant and suitable for use in green products. NXP's commitment to quality ensures that this ESD protection device meets the highest standards for reliability and performance.
