The ESDALC6V1-1BT2 is a state-of-the-art Transil™ diode designed by STMicroelectronics, specifically engineered to provide superior protection against Electrostatic Discharge (ESD) for sensitive electronic components. This robust device is a must-have for any application where electronic circuits are at risk of damage from ESD events, ensuring the longevity and reliability of your products.

Key Features

• ESD Protection: It offers an excellent clamping capability with a low clamping voltage, effectively safeguarding sensitive circuitry from ESD strikes as defined in IEC 61000-4-2.
• High Integration: The single-line design makes it an ideal choice for protecting one data line or other I/O port with minimal board space requirements.
• Low Leakage Current: The device maintains a low leakage current, thereby ensuring minimal impact on the normal operation of the protected circuit.
• Fast Response Time: The ESDALC6V1-1BT2 reacts swiftly to transient events, offering immediate protection upon detection of an ESD strike.
• Peak Pulse Power: With a peak pulse power of 200 W (8/20 µs), it can handle significant energy associated with transient events.

Applications

The versatility of the ESDALC6V1-1BT2 makes it suitable for a wide range of applications, including:

• Protection of data lines on mobile phones, tablets, and other portable devices.
• USB power and data line protection.
• Protection for HDMI, Ethernet, and other high-speed data interfaces.
• General ESD protection for integrated circuits and other sensitive electronics.

Package and Quality Assurance

The ESDALC6V1-1BT2 is packaged in a small SOD-523 package, which is suitable for high-density board layouts. STMicroelectronics ensures that each device meets rigorous quality standards, providing reliability and performance that engineers can trust for their critical applications.

By integrating the ESDALC6V1-1BT2 into your design, you can significantly enhance the ESD robustness of your electronic products, ensuring they withstand the rigors of everyday use and accidental static discharges. Protect your investments and maintain the integrity of your electronic systems with this exceptional ESD protection solution from STMicroelectronics.
