KBPC3510 SEP
Same model may have multiple batches, images only for reference.

KBPC3510

Part No KBPC3510
Manufacturer Solid State Inc.
Catalog Bridge Rectifiers
Description 35 AMP BRIDGE RECTIFIER
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Discrete Semiconductor Products - Diodes - Bridge Rectifiers
Mfr Solid State Inc.
Package Box
Product Status Active
Diode Type Single Phase
Technology Standard
Voltage - Peak Reverse (Max) 1 kV
Current - Average Rectified (Io) 35 A
Voltage - Forward (Vf) (Max) @ If 1.2 V @ 17.5 A
Current - Reverse Leakage @ Vr 10 µA @ 1000 V
Temperature Range - Operating -55°C ~ 125°C (TJ)
Mounting Type Chassis Mount
Package / Case 4-Square, KBPC
Supplier Device Package KBPC
Standard Package 1 pcs
MSL Level Not Applicable
ECCN EAR99
HTSUS 8541.10.0080
Win Source Part Number 168873-KBPC3510
Ultra Librarian 3D Model Ultra Librarian KBPC3510 CAD Model

Description

The 168873-KBPC3510 is a single-phase bridge rectifier used in discrete semiconductor applications.

  • Package: box
  • Standard Package: 1 piece
  • Maximum Average Rectified Current: 35A
  • Forward Voltage @ Current: 1.2V @ 17.5A
  • Reverse Leakage Current @ Reverse Voltage: 10 µA @ 1000V
  • Maximum Peak Reverse Voltage: 1kV
  • Mounting Type: chassis mount
  • Package: 4-square, KBPC
  • Manufacturer: Solid State Inc.
  • Status: active
  • Operating Temperature Range: -55°C to 125°C
  • ECCN: EAR99
  • Category: discrete semiconductor products - diodes - bridge rectifiers
  • MSL Level: not applicable
  • HTSUS Code: 8541.10.0080
