3.0SMCJ22A

Name: 3.0SMCJ22A
Brand: SMC Diode Solutions
SKU: 1037887
Availability: InStock
Rating: 4.85 (5 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	3.0SMCJ22A
Manufacturer	SMC Diode Solutions
Catalog	TVS - Diodes
Description	TVS DIODE 22VWM 35.5VC SMC / 35.5V Clamp 84.4A Ipp Tvs Diode Surface Mount SMC (DO-214AB)
Datasheet	3.0SMCJ22A Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Circuit Protection>TVS - Diodes
Mfr	SMC Diode Solutions
Package	Tape & Reel (TR)
Type	Zener
Unidirectional Channels	1
Voltage - Reverse Standoff (Typ)	22V
Voltage - Breakdown (Min)	24.4V
Voltage - Clamping (Max) @ Ipp	35.5V
Current - Peak Pulse (10/1000µs)	84.4A
Power - Peak Pulse	3000W (3kW)
Power Line Protection	No
Applications	General Purpose
Temperature Range - Operating	-55°C ~ 150°C (TJ)
Mounting	SMD (SMT)
Package / Case	DO-214AB, SMC
Supplier Device Package	SMC (DO-214AB)
MSL Level	1 (Unlimited)
REACH Status	REACH Affected
ECCN	EAR99
HTSUS	8541.10.0080
Other Names	3.0SMCJ22ATRSMC-ND,3.0SMCJ22ATR,1655-3.0SMCJ22ATR,3.0SMCJ22ATRSMC
Standard Package	3,000
Win Source Part Number	1037887-3.0SMCJ22A
Ultra Librarian 3D Model	Ultra Librarian 3.0SMCJ22A CAD Model

Description

The 3.0SMCJ22A is a unidirectional TVS diode from SMC Diode Solutions.

Function: Protection against voltage spikes and surges
Series: SMC
Package Type: Tape and reel
Standard Package: 3,000
Reverse Standoff Voltage: 22V
Breakdown Voltage: 24.4V
Maximum Clamping Voltage @ Ipp: 35.5V
Peak Pulse Power: 3kW
Current Peak Pulse: 84.4A
Application: General-purpose power line protection
ECCN: EAR99
MSL Level: 1
HTSUS Code: 8541.10.0080
Market Status: Open market
