SE5004L-R Skyworks Solutions Inc. SE5004L-R Real Image SE5004L-R real image5331
Same model may have multiple batches, images only for reference.
SE5004L-R Skyworks Solutions Inc. SE5004L-R Real Image SE5004L-R real image5331
SE5004L-R Skyworks Solutions Inc. SE5004L-R Real Image SE5004L-R real image5331
Same model may have multiple batches, images only for reference.

SE5004L-R

Part No SE5004L-R
Manufacturer Skyworks Solutions Inc.
Catalog RF Amplifiers
Description 26dBm Power Amplifier with Power Detector / IC PWR AMP 5GHZ 20QFN
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories RF/IF and RFID
Manufacturer Skyworks Solutions Inc.
Packaging Reel - TR
Status Active
Frequency 5.15GHz to 5.85GHz
P1dB 34dBm
Gain 32dB
RF Type 802.11a/n
Supply Voltage - Operating 3 V to 5.5 V
Operating Supply Current 600mA
Test Frequency 5.15GHz to 5.85GHz
Case / Package 20-QFN (4x4)
Win Source Part Number 028227-SE5004L-R
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Family Name SE5004L
Introduction Date March 14, 2011
Estimated EOL Date 2026
Ultra Librarian 3D Model Ultra Librarian SE5004L-R CAD Model

Description

The Skyworks Solutions Inc. RF amplifier is a high-quality component that is used in various electronic devices.

  • Manufacturer: Skyworks Solutions Inc.
  • Popularity: High
  • Supply and Demand: Limited
  • Manufacturer Part Number: 028227-SE5004L-R
  • Category: RF/IF and RFID
  • Part Name: SE5004L-R
  • Alternative Parts: SE5004L
  • Introduction Date: March 14, 2011
  • Estimated Obsolescence: 2026
  • Gain: 32dB
  • P1dB: 34dBm
  • Frequency: 5.15GHz to 5.85GHz
