The SST39VF010-70-4C-W is a 1 Mbit Multi-Purpose Flash (MPF) manufactured by Silicon Storage Technology (SST). It's based on CMOS technology and offers low power consumption, making it suitable for various embedded systems and portable applications. This memory device is organized as 128K x8, providing byte-wide access. It operates at 2.7-3.6V and features a fast read access time of 70ns.

Applications

• Embedded systems requiring non-volatile memory
• Microcontroller code storage
• Data logging applications
• Portable electronic devices
• Firmware storage

Features

• 1 Mbit Flash Memory: Organized as 128K x8.
• Fast Read Access Time: 70 ns access time for quick data retrieval.
• Low Power Consumption: Active current of 10 mA (typical) and standby current of 4 μA (typical).
• CMOS Multi-Purpose Flash (MPF): Utilizing CMOS technology for efficient operation.
• Single Voltage Read and Write Operations: Operates from 2.7V to 3.6V.
• Superior Reliability: Endurance of 100,000 cycles (typical).
• Sector Erase Capability: Allows for selective erasure of memory blocks.
• Fast Erase and Byte-Program: Reduces programming time.
• Automatic Write Timing: Simplifies the write process.
• End-of-Write Detection: Provides status information for successful write operations.
• JEDEC Standard Packaging: Available in industry-standard packages for ease of integration.

Benefits

• Fast data access improves system performance.
• Low power consumption extends battery life in portable devices.
• High endurance ensures long-term data retention.
• Sector erase capability allows for efficient memory management.
• Easy integration due to JEDEC standard packaging.
• Cost-effective solution for non-volatile memory requirements.

Technical Specifications

The SST39VF010-70-4C-W operates within a temperature range of -40°C to +85°C. It supports a minimum of 100,000 erase/write cycles per sector. The device utilizes a command sequence to initiate erase and write operations, ensuring data integrity. Packaging options typically include TSOP and PDIP. Detailed timing diagrams and electrical characteristics are available in the manufacturer's datasheet.
