PC3SD12NTZAF Sharp Microelectronics PC3SD12NTZAF Real Image PC3SD12NTZAF real image4456
Same model may have multiple batches, images only for reference.
PC3SD12NTZAF Sharp Microelectronics PC3SD12NTZAF Real Image PC3SD12NTZAF real image4456
PC3SD12NTZAF Sharp Microelectronics PC3SD12NTZAF Real Image PC3SD12NTZAF real image4456
Same model may have multiple batches, images only for reference.

PC3SD12NTZAF

Part No PC3SD12NTZAF
Manufacturer Sharp Microelectronics
Catalog Optoisolators - Triac, SCR Output
Description OPTOISOLATOR 5KV TRIAC 6DIP / Optocoupler Triac AC-OUT 1-CH 600V 5-Pin PDIP Sleeve
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer Sharp Microelectronics
Packaging Tube/Rail
Status Obsolete(EOL)
Output Type Triac
Zero Crossing Circuit No
Number of Channels 1
Isolation Voltage 5000Vrms
Voltage - Off State 600V
Static dV/dt (Min) 1kV/μs
Current - LED Trigger (Ift) (Max) 10mA
Current - On State (It (RMS)) (Max) 100mA
Current - Hold (Ih) 3.5mA
Turn On Time 50μs (Max)
Forward Voltage 1.2V
Continuous forward current- Max 50mA
Temperature Range - Operating -30°C to 100°C
Mounting Through Hole
Case / Package 6-DIP
Approvals CSA, UR
Win Source Part Number 092421-PC3SD12NTZAF
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Family Name PC3SD12
Introduction Date March 23, 2004
ECCN EAR99
Country of Origin China, Indonesia, Japan, Philippines
Estimated EOL Date Obsolete / End of life
Ultra Librarian 3D Model Ultra Librarian PC3SD12NTZAF CAD Model

Description

The Sharp Microelectronics 092421-PC3SD12NTZAF is an electronic component that belongs to the isolator category.

  • Supply and Demand Status: sufficient
  • Output Type: triac
  • Voltage-Off State: 600V
  • Current-On State (It (RMS)) (Max): 100mA
  • Isolation Voltage: 5000Vrms
  • Continuous Forward Current-Max: 50mA
  • Turn-On Time: 50μs (Max)
