The SR1080 is a Schottky Barrier Rectifier designed for high-efficiency rectification in various power applications. It is manufactured by Shanghai Lunsure Electronic Tech and is recognized for its low forward voltage drop and fast switching speed.

Applications:

• Switching power supplies
• Free-wheeling diodes
• Polarity protection applications
• Reverse current protection
• DC-DC converters

Features:

• High Surge Capability
• Low Forward Voltage Drop
• High Switching Speed
• High Reliability
• RoHS Compliant

Benefits:

• Increased efficiency in power conversion due to low forward voltage drop.
• Reduced power loss and heat generation, leading to improved system performance.
• Enhanced system reliability due to high surge capability.
• Suitable for high-frequency applications because of the fast switching speed.
• Environmentally friendly due to RoHS compliance.

Specifications:

The SR1080 typically features a repetitive peak reverse voltage of 80V and a forward current of 10A. It is commonly available in a DO-201AD package. Its operating junction temperature typically ranges from -65°C to +150°C. The low forward voltage drop is typically around 0.70V at 10A.
