SRDA05-6.TBT Semtech Corporation SRDA05-6.TBT real image SRDA05-6.TBT label picture
Same model may have multiple batches, images only for reference.
SRDA05-6.TBT Semtech Corporation SRDA05-6.TBT real image SRDA05-6.TBT label picture
SRDA05-6.TBT Semtech Corporation SRDA05-6.TBT real image SRDA05-6.TBT label picture
Same model may have multiple batches, images only for reference.

SRDA05-6.TBT

Part No SRDA05-6.TBT
Manufacturer Semtech Corporation
Catalog TVS - Diodes
Description TVS DIODE 5VWM 20VC 8SOIC
Datasheet
SRDA05-6.TBT Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Circuit Protection
Manufacturer Semtech Corporation
Packaging Reel - TR
Status Active
Type Steering (Rail to Rail)
Unidirectional Channels 6
STAND-OFF Voltage (Vwm) 5V (Max)
Minimum Breakdown Voltage 6V
Max Clamping Voltage 20V
Peak Pulse Current(Ippm) 25A (8/20μs)
Power Dissipation - Pd 500W
Power Line Protection Yes
Applications General Purpose
Capacitance @ Frequency 8pF @ 1MHz
Temperature Range - Operating -55°C to 125°C (TJ)
Mounting SMD (SMT)
Case / Package 8-SO
Win Source Part Number 030803-SRDA05-6.TBT
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian SRDA05-6.TBT CAD Model

Description

The Semtech Corporation Steering (Rail to Rail) diode is a general-purpose component that provides circuit protection. This SMD (SMT) component comes in an 8-SO package and has 6 unidirectional channels.

  • The capacitance: of this diode is 8pF @ 1MHz.
  • The STAND-OFF voltage: is 5V (Max) and the minimum breakdown voltage: is 6V.
  • The maximum clamping voltage: is 20V and the peak pulse current(Ippm): is 25A (8/20μs).
  • The power dissipation - Pd -: is 500W.
  • This component is popular and has a balance in supply and demand.
