ECLAMP2422N.TCT Semtech Corporation ECLAMP2422N.TCT real image ECLAMP2422N.TCT label picture
Same model may have multiple batches, images only for reference.
ECLAMP2422N.TCT Semtech Corporation ECLAMP2422N.TCT real image ECLAMP2422N.TCT label picture
ECLAMP2422N.TCT Semtech Corporation ECLAMP2422N.TCT real image ECLAMP2422N.TCT label picture
Same model may have multiple batches, images only for reference.

ECLAMP2422N.TCT

Part No ECLAMP2422N.TCT
Manufacturer Semtech Corporation
Catalog EMI/RFI Filters (LC, RC Networks)
Description FILTER LC(PI) 2NH/100PF ESD SMD
Datasheet
ECLAMP2422N.TCT Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Filters
Manufacturer Semtech Corporation
Packaging Reel - TR
Status Active
Type Low Pass
Filter Order 3rd
Technology LC (Pi)
Number of Channels 2
Attenuation Value 20dB @ 800MHz to 2.7GHz
Resistance - Channel (Ohms) 1.4
Values L = 2nH, C = 100pF
ESD Protection Yes
Temperature Range - Operating -40°C to 85°C
Applications Data Lines for Mobile Devices
Mounting SMD (SMT)
Dimension 0.057" L x 0.039" W (1.45mm x 1.00mm)
Height 0.026" (0.65mm)
Win Source Part Number 015157-ECLAMP2422N.TCT
Family Name EClamp2422N
Introduction Date May 18, 2007
ECCN EAR99
Country of Origin China
Halogen Free Compliant
Estimated EOL Date 2023
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian ECLAMP2422N.TCT CAD Model

Description

Product Overview

The ECLAMP2422N.TCT offers robust protection against ESD and voltage spikes, specifically designed for environments requiring high reliability and performance.

Features and Benefits

  • Superior ESD protection for enhanced durability
  • Low leakage current
  • Compact form factor for versatile application
  • Simplifies circuit design with easy implementation

Applications

  • Computing devices
  • Industrial control systems
  • Medical equipment
  • Wearable technology

The ECLAMP2422N.TCT is optimal for safeguarding electronics in mission-critical applications.
