FN7611-16-M4

Part No FN7611-16-M4
Manufacturer TE Connectivity
Catalog EMI/RFI Filters (LC, RC Networks)
Description FILTER LC(PI) 70NH/0.022UF BOLT
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Type Low Pass
Filter Order 3rd
Technology LC (Pi)
Number of Channels 1
Resistance - Channel (Ohms) 0.00065
Current 16 A
Values L = 70nH, C = 0.022µF
ESD Protection No
Temperature Range - Operating -40°C ~ 100°C
Applications Data Lines for Mobile Devices
Voltage - Rated 1000V (1kV)
Mounting Type Bolt Mount
Case / Package Axial - Threaded Terminals
Size / Dimension 0.984" Dia x 3.268" L (25.00mm x 83.00mm)
Package Tray
Supply and Demand Status Shortage
Win Source Part Number 1527312-FN7611-16-M4
Ultra Librarian 3D Model Ultra Librarian FN7611-16-M4 CAD Model
