MSM19-NX0005A-SNCSNCNF-RI0GN024-Q0000-S Schurter Inc. – Price, Stock & Datasheet
Same model may have multiple batches, images only for reference.

MSM19-NX0005A-SNCSNCNF-RI0GN024-Q0000-S

Part No MSM19-NX0005A-SNCSNCNF-RI0GN024-Q0000-S
Manufacturer Schurter Inc.
Catalog Pushbutton Switches
Description MSM 19, METAL SWITCH, 5 / 3 A SW
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Product Status Obsolete
Mounting Type Panel Mount, Front
Type Anti-Vandal, Illuminated
Circuit SPDT
Switch Function On-Mom
Current Rating (Amps) 5A (AC)
Voltage Rating - AC 125 V
Actuator Type Round, Button, Flush
Actuator Marking No Marking
Color - Actuator/Cap Silver
Illumination Type, Color LED, Green
Illumination Voltage (Nominal) 24 VDC
Termination Style Quick Connect - 0.110" (2.8mm)
Ingress Protection IP40
Panel Cutout Dimensions Circular - 19.10mm Dia
Temperature Range - Operating -25°C ~ 85°C
Package Bulk
Supply and Demand Status Shortage
Win Source Part Number 1508765-MSM19-NX0005A-SNCSNCNF-RI0GN024-Q0000-S
Ultra Librarian 3D Model Ultra Librarian MSM19-NX0005A-SNCSNCNF-RI0GN024-Q0000-S CAD Model
