3404.0020.24 Real Image
Same model may have multiple batches, images only for reference.

3404.0020.24

Part No 3404.0020.24
Manufacturer Schurter Inc.
Catalog Fuses
Description FUSE BRD MNT 8A 125VAC/VDC 2SMD
Datasheet
3404.0020.24 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Circuit Protection
Manufacturer Schurter Inc.
Packaging Reel - TR
Status Active
Fuse Type Board Mount (Cartridge Style Excluded)
Current Rating 8A
Voltage Rating - AC 125V
Voltage Rating - DC 125V
Response Time Fast
Mounting SMD (SMT)
Breaking Capacity @ Rated Voltage 100A
Nominal Melting - I2t 20
Approvals cURus
Temperature Range - Operating -55°C to 125°C
Dimension 0.291" L x 0.122" W x 0.102" H (7.40mm x 3.10mm x 2.60mm)
Win Source Part Number 197667-3404.0020.24
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian 3404.0020.24 CAD Model

Description

Product Overview

The 3404.0020.24 stands out with its impressive specifications designed for efficiency and performance in modern electronics.

Features and Benefits

  • High Efficiency: Supports reduced power usage in operation.
  • Versatile Application: Suitable for a wide range of electronic systems.
  • Advanced Optimization: Fine-tuned for optimal performance in diverse environments.

Applications

  • Home Automation
  • Network Systems
  • Automotive Electronics
  • High-tech Gadgets

The 3404.0020.24 is engineered to meet the needs of cutting-edge technology projects requiring high efficiency and reliability.
