3404.0012.24 Real Image
Same model may have multiple batches, images only for reference.

3404.0012.24

Part No 3404.0012.24
Manufacturer Schurter Inc.
Catalog Fuses
Description FUSE BOARD MNT 2A 125VAC/VDC SMD
Datasheet
3404.0012.24 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Circuit Protection
Manufacturer Schurter Inc.
Packaging Reel - TR
Status Active
Fuse Type Board Mount (Cartridge Style Excluded)
Current Rating 2A
Voltage Rating - AC 125V
Voltage Rating - DC 125V
Response Time Fast
Mounting SMD (SMT)
Breaking Capacity @ Rated Voltage 100A
Nominal Melting - I2t 0.44
Approvals cURus
Temperature Range - Operating -55°C to 125°C
Dimension 0.291" L x 0.122" W x 0.102" H (7.40mm x 3.10mm x 2.60mm)
Win Source Part Number 1005151-3404.0012.24
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian 3404.0012.24 CAD Model

Description

The Schurter Inc. 3404.0012.24 Fuse is a board mount (cartridge style excluded) fuse that comes with a current rating of 2A and a voltage rating of 125V (AC/DC).

  • Type: Board Mount (Cartridge Style Excluded)
  • Current Rating: 2A
  • Voltage Rating: 125V (AC/DC)
  • Response Time: Fast
  • Breaking Capacity: 100A @ Rated Voltage
  • Operating Temperature: -55°C to 125°C
  • Mounting Type: SMD (SMT)
  • Nominal Melting - I2t: 0.44
  • Approvals: cURus
  • Dimensions: 0.291" L x 0.122" W x 0.102" H (7.40mm x 3.10mm x 2.60mm)
  • Packaging: Reel - TR
