3402.0009.24

Part No 3402.0009.24
Manufacturer Schurter Inc.
Catalog Fuses
Description FUSE BOARD MNT 1A 63VAC/VDC 2SMD
Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Circuit Protection
Manufacturer Schurter Inc.
Packaging Reel - TR
Status Active
Fuse Type Board Mount (Cartridge Style Excluded)
Current Rating 1A
Voltage Rating - AC 63V
Voltage Rating - DC 63V
Response Time Fast
Mounting SMD (SMT)
Breaking Capacity @ Rated Voltage 50A
Nominal Melting - I2t 0.078
Approvals cURus
Temperature Range - Operating -55°C to 125°C
Dimension 0.291" L x 0.122" W x 0.102" H (7.40mm x 3.10mm x 2.60mm)
Win Source Part Number 197651-3402.0009.24
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian 3402.0009.24 CAD Model

Description

Product Description

The 3402.0009.24 component offers a versatile solution for developers and engineers looking to enhance system functionality. Its robust construction and superior technology make it a prime choice for modern applications.

Applications

  • Embedded Systems
  • Telecommunications
  • Medical Devices
  • Renewable Energy Equipment

Features and Benefits

  • Energy Efficient: Reduces energy consumption to improve sustainability.
  • High Compatibility: Easily integrates with multiple systems and platforms.
  • Reliable Operation: Guarantees stable and error-free functionality over long periods.

Additional Details

Compatible with a variety of materials and setups, making it a highly flexible component for diverse uses.
