RSL1PVEU Schneider Electric – Price, Stock & Datasheet
Same model may have multiple batches, images only for reference.

RSL1PVEU

Part No RSL1PVEU
Manufacturer Schneider Electric
Catalog Power Relays, Over 2 Amps
Description HARMONY, SLIM INTERFACE RELAY PR
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Mounting Type DIN Rail
Coil Voltage 48VDC
Contact Form SPDT (1 Form C)
Contact Rating (Current) 6 A
Switching Voltage 277VAC - Max
Load - Max Switching 1662VA
Coil Current 4.5 mA
Coil Type Non Latching
Features Lighted Indicator
Termination Style Screw Terminal
Must Operate Voltage 38.4 VDC
Must Release Voltage 2.4 VDC
Operate Time 5 ms
Release Time 12 ms
Temperature Range - Operating -40°C ~ 55°C
Contact Material Silver Tin Oxide (AgSnO)
Approval Agency CSA, GOST, UL
Relay Type General Purpose
Package Box
Supply and Demand Status Shortage
Win Source Part Number 1549482-RSL1PVEU
Ultra Librarian 3D Model Ultra Librarian RSL1PVEU CAD Model
