TSW-110-15-T-D

Name: TSW-110-15-T-D
Brand: Samtec Inc.
SKU: 692229
Availability: InStock
Rating: 4.85 (5 reviews)

Get a Quote

Part No	TSW-110-15-T-D
Manufacturer	Samtec Inc.
Catalog	Rectangular Connectors
Description	THROUGH-HOLE .025" SQ POST HEADER \| CONN HEADER VERT 20POS 2.54MM
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Connectors, Interconnects
Manufacturer	Samtec Inc.
Packaging	Bulk
Connector Type	Header
Contact Type	Male Pin
Pitch - Mating	0.100" (2.54mm)
Number of Positions	20
Number of Rows	2
Row Spacing - Mating	0.100" (2.54mm)
Number of Positions Loaded	All
Style	Board to Board or Cable
Shrouding	Unshrouded
Mounting Style	Through Hole
Termination	Solder
Fastening Type	Push-Pull
Contact Length - Mating	0.520" (13.21mm)
Contact Length - Post	0.110" (2.79mm)
Overall Contact Length	0.730" (18.54mm)
Insulation Height	0.100" (2.54mm)
Contact Shape	Square
Contact Finish - Mating	Tin
Contact Finish - Post	Tin
Contact Material	Phosphor Bronze
Insulation Material	Polybutylene Terephthalate (PBT)
Temperature Range - Operating	-55°C ~ 105°C
Material Flammability Rating	UL94 V-0
Insulation Color	Black
Manufacturer Pack Quantity	1
Win Source Part Number	1274917-TSW-110-15-T-D
Manufacturer Homepage	www.samtec.com/
Popularity	Medium
Supply and Demand Status	Limited
Application Field	Used in Industrial
Ultra Librarian 3D Model	Ultra Librarian TSW-110-15-T-D CAD Model

Description

The Samtec Inc. 1274917-TSW-110-15-T-D is a male pin header connector that has 20 positions and is designed for board to board or cable applications.

Positions: 20
Applications: Board to board or cable
Packaging: Bulk
Popularity: Medium
Supply and demand status: Limited
Pitch-Mating: 0.100" (2.54mm)
Contact Finish-Mating: Tin
Contact Finish-Post: Tin
Temperature Range: -55°C to 105°C
