Same model may have multiple batches, images only for reference.

TFM-107-02-L-DH

Name: TFM-107-02-L-DH
Brand: Samtec Inc.
SKU: 969882
Availability: InStock
Rating: 4.85 (5 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	TFM-107-02-L-DH
Manufacturer	Samtec Inc.
Catalog	Rectangular Connectors
Description	CONN HEADER SMD 14POS 1.27MM / Connector Header Surface Mount 14 position 0.050" (1.27mm)
Datasheet	TFM-107-02-L-DH Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Connectors, Interconnects>Rectangular Connectors - Headers, Male Pins
Mfr	Samtec Inc.
Series	Tiger Eye™ TFM
Package	Tube
Connector Type	Header
Contact Type	Male Pin
Pitch - Mating	0.050" (1.27mm)
Number of Positions	14
Number of Rows	2
Row Spacing - Mating	0.050" (1.27mm)
Number of Positions Loaded	All
Style	Board to Board or Cable
Shrouding	Shrouded - 4 Wall
Mounting	SMD (SMT)
Termination	Solder
Fastening Type	Push-Pull
Contact Length - Mating	0.131" (3.33mm)
Insulation Height	0.220" (5.60mm)
Contact Shape	Square
Contact Finish - Mating	Gold
Contact Finish Thickness - Mating	15.0µin (0.38µm)
Contact Finish - Post	Tin
Contact Material	Phosphor Bronze
Insulation Material	Liquid Crystal Polymer (LCP)
Temperature Range - Operating	-55°C ~ 125°C
Material Flammability Rating	UL94 V-0
Insulation Color	Black
Current Rating (Amps)	2.9A per Contact
Voltage Rating	275VAC
Base Product Number	TFM-107
MSL Level	1 (Unlimited)
REACH Status	REACH Unaffected
ECCN	EAR99
HTSUS	8536.69.4040
Other Names	SAM10110
Standard Package	36
Win Source Part Number	969882-TFM-107-02-L-DH
Ultra Librarian 3D Model	Ultra Librarian TFM-107-02-L-DH CAD Model

Alternative Products

Description

The Tiger Eye™ TFM series header connector from Samtec Inc. is a board-to-board or cable connector that is suitable for use in a variety of applications. The Samtec Inc. Tiger Eye™ TFM series is the manufacturer.

Connector Type: Board-to-Board or Cable Connector
Number of Rows: 2
Number of Pins: 14 Male
Connector Category: Rectangular Connectors - Headers, Male Pins
Termination: Solder
Fastening Type: Push-Pull
Contact Material: Phosphor Bronze
Voltage Rating: 275VAC
Shrouding: 4 Walls
Insulation Material: Liquid Crystal Polymer (LCP)
Mating Pitch: 0.050" (1.27mm)
Contact Finish - Mating: Gold with a thickness of 15.0µin (0.38µm)
Contact Finish - Post: Tin
Temperature Range: -55°C to 125°C
Current Rating: 2.9A per contact
Standard Package: 36
Mounting: SMD (SMT)
