NX3225SA-16.000000MHZ-B3 Real Image NX3225SA-16.000000MHZ-B3 Real Image
Same model may have multiple batches, images only for reference.
NX3225SA-16.000000MHZ-B3 Real Image NX3225SA-16.000000MHZ-B3 Real Image
NX3225SA-16.000000MHZ-B3 Real Image NX3225SA-16.000000MHZ-B3 Real Image
Same model may have multiple batches, images only for reference.

NX3225SA-16.000000MHZ-B3

Part No NX3225SA-16.000000MHZ-B3
Manufacturer NDK
Catalog Oscillators
Description CRYSTAL 16.0000MHZ 7.2PF SMD
Datasheet
NX3225SA-16.000000MHZ-B3 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Crystals, Oscillators, Resonators - Crystals
Mfr NDK
Series NX3225SA
Package Tape & Reel
Product Status Active
Type MHz Crystal
Frequency 16 MHz
Frequency Stability ±15ppm
Frequency Tolerance ±10ppm
Load Capacitance 7.2pF
ESR (Equivalent Series Resistance) 80 Ohms
Operating Mode Fundamental
Temperature Range - Operating -30°C ~ 85°C
Mounting Type Surface Mount
Package / Case 4-SMD, No Lead
Size / Dimension 0.126" L x 0.098" W (3.20mm x 2.50mm)
Height - Seated (Max) 0.028" (0.70mm)
Standard Package 3,000 pcs
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8541.60.0050
Win Source Part Number 845284-NX3225SA-16.000000MHZ-B3
Ultra Librarian 3D Model Ultra Librarian NX3225SA-16.000000MHZ-B3 CAD Model

Description

The 845284-NX3225SA-16.000000MHZ-B3 is a MHz crystal from the NX3225SA series.

  • Packaging: Tape & Reel (TR)
  • Size / Dimension: 0.126" L x 0.098" W (3.20mm x 2.50mm)
  • Height - Seated (Max): 0.028" (0.70mm)
  • Packaging: 3,000 pcs
  • Frequency: 16 MHz
  • ESR (Equivalent Series Resistance): 80 Ohms
  • Frequency Stability: ±15ppm
  • Frequency Tolerance: ±10ppm
  • Mode: Fundamental
  • Mounting Type: Surface Mount
  • Operating Temperature: -30°C ~ 85°C
  • ECCN: EAR99
  • HTSUS: 8541.60.0050
