The SSA-125-W-G is a rectangular connector electronic component manufactured by Samtec Inc.

• Category: Connectors, Interconnects>Rectangular Connectors - Headers, Receptacles, Female Sockets
• Series: SSA series
• Number of Positions: 25
• Connector Type: receptacle, breakaway
• Contact Type: female socket
• Number of Positions Loaded: all
• Number of Rows: 1
• Termination: wire wrap
• Fastening Type: push-pull
• Package: bulk
• Contact Material: phosphor bronze
• Voltage Rating: 1000V
• Mated Stacking Heights: not specified
• Ingress Protection: not specified
• Material Flammability Rating: not specified
• Standard Package: 1
• Insulation Material: polyethylene terephthalate (PET), polyester
• Style: board to board
• Pitch - Mating: 0.100" (2.54mm)
• Contact Finish - Mating: gold
• Contact Finish Thickness - Mating: 10.0µin (0.25µm)
• Contact Finish - Post: not specified
• Contact Finish Thickness - Post: not specified
• Insulation Color: black
• Mounting Type: through hole
• Row Spacing - Mating: not specified
• Contact Length - Post: 0.656" (16.66mm)
• Insulation Height: 0.230" (5.85mm)
• Contact Shape: not specified
• Temperature Range - Operating: -55°C ~ 125°C
• MSL Level: 1 (Unlimited)
• Current Rating (Amps): not specified
• REACH Status: REACH unaffected
• HTSUS: 8536.69.4040
• Other Names: SAM1123-25
• Base Product Number: SSA-125
