Name: SQT-115-03-F-D
Brand: Samtec Inc.
SKU: 1292357
Availability: InStock
Rating: 4.85 (5 reviews)

Products specifications Report Issue?

Category	Connectors, Interconnects>Rectangular Connectors - Headers, Receptacles, Female Sockets
Mfr	Samtec Inc.
Series	SQT
Connector Type	Receptacle
Contact Type	Forked
Style	Board to Board or Cable
Number of Positions	30
Number of Positions Loaded	All
Pitch - Mating	0.079" (2.00mm)
Number of Rows	2
Row Spacing - Mating	0.079" (2.00mm)
Mounting Type	Through Hole
Termination	Solder
Fastening Type	Push-Pull
Contact Finish - Mating	Gold
Contact Finish Thickness - Mating	Flash
Insulation Color	Black
Insulation Height	0.250" (6.35mm)
Contact Length - Post	0.208" (5.28mm)
Temperature Range - Operating	-55°C ~ 125°C
Material Flammability Rating	UL94 V-0
Contact Finish - Post	Tin
Current Rating (Amps)	5.1A per Contact
Insulation Material	Liquid Crystal Polymer (LCP)
Contact Shape	Square
Contact Material	Phosphor Bronze
Base Product Number	SQT-115
Other Names	SAM9992
Standard Package	18
MSL Level	1 (Unlimited)
ECCN	EAR99
HTSUS	8536.69.4040
Win Source Part Number	1292357-SQT-115-03-F-D
Ultra Librarian 3D Model	Ultra Librarian SQT-115-03-F-D CAD Model

Description

The SQT series connector from Samtec Inc. is a rectangular connector that is suitable for board-to-board or cable applications.

Connector Type: Receptacle
Contact Type: Forked
Loaded: All positions
Rows: Two
Termination: Solder
Fastening Type: Push-Pull
Contact Material: Phosphor Bronze
Insulation Material: Liquid Crystal Polymer (LCP)
Insulation Color: Black
Contact Finish (Mating): Gold with flash finish thickness
Contact Finish (Post): Tin
Contact Shape: Square
Contact Length (Post): 0.208 inches (5.28mm)
Insulation Height: 0.250 inches (6.35mm)
Row Spacing (Mating): 0.079 inches (2.00mm)
Operating Temperatures: -55°C to 125°C
Current Rating: 5.1A per contact
Voltage Rating: Not Specified
Standard Package: 18
